Key Specifications/Special Features
- INPUT :
- DC4.75V to DC5.25V NORMAL= 5V
- OUTPUT :
- Output voltage and current: +24V
- Max load: 0.5A
- Power: 12W maximum
- Minimum load: 0.1A
- Load regular percentage: 5%
- Line regular percentage: 1%
- Ripple percentage: 1%
- Noise percentage: 5%
- Total power: 6W
- Ripple & Noise bandwidth is from DC to 20Mhz.
- Terminated With a 47uF Capacitor and 0.1uf MPE Capacitor of Proper Polarity.
- To match up PSE
- Efficiency: 72% min @5Vin dc (include USB contact loss)
- Protection:
- Short Circuit Protection
- Output Short GND Terminal will not damage the Power Supply and will Auto-Reset
- Over Load Protection is Current Limits mode , auto-recovery
- Operation frequency is 70KHZ
- Isolation Voltage : NO Isolation.
- General description:
- Operating temperature: -25 to 50 degree Celsius
- Storage temperature: -40 to 85 degree Celsius
- Operating humidity: 5% - 90% 45 Degree
- Free air cooling
- Plastic Case Material: ABS
- Plastic Case Color: BLACK
- Plastic Case Dimension: 85mm (L) * 78mm (W) * 36mm (H)
- Connector assignment:
- Voltage INPUT : USB
- 8P8C Input Socket (per channel) data
- Power-Hub RJ45 Output Socket (per channel) data & Power-Connected to DTE
